Description

The NEEDLE GUIDE ULTRA-PRO II by CIVCO is an advanced in-plane ultrasound needle guidance system, meticulously designed to enhance precision in ultrasound-guided procedures. This innovative tool significantly improves needle visualization, fostering increased clinical confidence while reducing procedure time and the number of needle passes required. As a result, it enhances both patient safety and comfort.

Key Features

• Versatile Applications: Ideal for a variety of procedures including tissue biopsy, fluid aspiration, catheter placement, nerve blocks, joint infiltration, and ablations.
• Needle Guide Options: Available as a disposable, snap-on guide with configurations that may include non-sterile, reusable options.
• Custom Bracket: Features a reusable bracket with multi-angle or single-angle options tailored to specific needs.

Compatibility

The system boasts extensive compatibility with a wide array of ultrasound transducers from leading manufacturers such as GE Healthcare, Siemens, Philips, and many others. Each configuration is specifically tailored to match particular transducer models, ensuring seamless integration.

Design and Functionality

• Needle Size Compatibility: Accommodates sizes 8.5FR and 14-23GA (excluding 19GA), with a large funnel for easy instrument insertion.
• Gauge Identification: Equipped with easy-to-read gauge size inserts for straightforward identification, even in low-light conditions.
• Attachment Mechanism: Features a secure snap-on mechanism with a large tab for quick-release, allowing easy detachment from the transducer.

Sterile Field Management

The system includes CIV-Flex™ sterile, latex-free covers that are telescopically folded, available in various sizes to expand the sterile field by covering the transducer and cord. Some kits also include a 3D 'box end' cover, enhancing versatility.

Cleaning and Maintenance

Brackets should be cleaned and disinfected according to the CIVCO User's Guide, with some kits providing a cleaning brush. Kit configurations vary, potentially including components such as the needle guide, bracket, CIV-Flex cover, cleaning brush, sterile gel packet, and colored elastic bands.

Clinical Benefits

Designed to keep the needle aligned with the ultrasound probe’s sound beam, the NEEDLE GUIDE ULTRA-PRO II improves needle tip visibility throughout procedures. It reduces technique variability and shortens the learning curve, particularly beneficial for novice users.

Material and Safety

Constructed from plastic with CIV-Flex™ covers, the system reduces cross-contamination risks when using disposable guides. It provides a fixed needle path aligned with on-screen ultrasound guidelines, limiting needle motion within the scan plane for enhanced accuracy and efficiency.

Patents

The design is protected under U.S. Patent Nos. 5,941,889 and 6,361,499, underscoring its unique contribution to medical technology.
