Description

The ECG MODULE USB PATIENT CABLE serves as a crucial accessory for PC-based electrocardiogram (ECG) systems, facilitating seamless connection between patients and ECG modules such as the EKG Master USB module. This cable is engineered to provide high-resolution ECG data acquisition through a USB interface, ensuring both data transfer and electrical power without the need for batteries or external adapters.

Key Features

• 12-Lead ECG Monitoring: Supports standard 12-lead ECG configurations, enabling comprehensive monitoring for up to one hour.
• Cable Variants: Available in clamp type and banana tip variants to suit different clinical needs.
• Patient Safety: Features defibrillator protection and minimal leakage current, complying with EN 60601-1 electrical safety and EN 60601-2 EMC standards. It is also CE certified.

Signal Integrity

• Shielding: The cable is electrically shielded to maintain ECG signal integrity.
• Sampling Rate: Offers a maximum sampling rate of 16,000 samples per second with a frequency response of 0.05 to 150 Hz.
• Conversion: Utilizes 24-bit A/D conversion with a dynamic range of 12 mV, along with leads-off detection and pacemaker detection.

Durability and Usability

• Chemical-Resistant Jacketing: Designed for durability, easy cleaning, and resistance to bending and twisting.
• Color-Coded Snaps: Clearly labeled and color-coded for easy setup, reducing errors in clinical environments.
• Reliability: Undergoes rigorous testing to ensure reliable performance.

Compatibility

Verified for use with GE HealthCare CARESCAPE devices, enhancing its versatility in various medical settings.

Maintenance and Cleaning

• Cleaning Instructions: Remove the cable from the device before cleaning. Use a lightly moistened cloth with mild soap and water, then air dry.
• Disinfection: Recommended to use sodium hypochlorite solution, avoiding contact with metal parts to prevent corrosion.
• Sterilization: Ethylene oxide gas (EtO) sterilization is permissible under specific conditions, while autoclave or steam cleaning is not recommended.
• Storage: Store in a dry, well-ventilated area, hanging vertically without tight coiling.

Cleaning Agents to Avoid

Avoid using ammonium chloride solutions, abrasive cleaners, acetone, and other specified agents to prevent risks such as discoloration, corrosion, and reduced lifespan.

Common Use Cases

Ideal for continuous ECG monitoring and long-term recording in clinical and hospital environments, this cable is designed to integrate seamlessly with PC-based ECG diagnostic systems, providing reliable and accurate performance.
