Description

The DUO-VAC Oocyte Pump is a specialized medical device engineered for precise oocyte aspiration, primarily utilized in in-vitro fertilization (IVF) and other gynecological procedures. Its design ensures smooth, low-turbulence recovery of oocytes by providing a controlled, low-volume vacuum at pre-determined negative pressures.

Key Features

• Vacuum Control: Offers infinitely variable vacuum settings with medium vacuum ranging from 0 to -200/250 mmHg and a high vacuum fixed at -440 mmHg. This allows for gentle aspiration and effective blockage clearance.
• Dual Footswitch Operation: Equipped with air-operated, toggle footswitches for hands-free control. The BLACK footswitch manages medium vacuum, while the WHITE footswitch handles high vacuum.
• Indicator Lights: Color-coded lights provide clear visual cues, with red indicating high vacuum and green indicating low vacuum.

Design and Operation

• Quiet Diaphragm Pump: Ensures minimal noise during operation.
• Vacuum Display: Features a large, clear gauge displaying vacuum in mmHg, alongside a control dial for easy adjustment.
• Power Management: Includes an illuminated mains power On/Off switch and a silencer with a filter chamber for enhanced performance.

Technical Specifications

• Power Input: Available in two models: R29660 (220-240 VAC) and R29661 (110-120 VAC).
• Dimensions: Measures 264mm in width, 124mm in height, and 164mm in depth, with a unit weight of 1.9kg.
• Protection and Compliance: Complies with IEC 60601-1 standards, offering Type B protection and EMC compliance.

Environmental Conditions

• Operating Temperature: Functions optimally between +5°C and +35°C.
• Storage Conditions: Can be stored between +5°C and +50°C, with atmospheric pressure ranging from 700 to 1060 hPa.

Components and Accessories

• Footswitches: Supplied with dual footswitches and a water trap connection port compatible with RS7685 Rocket CRAFT Water Trap Sets.
• Silicone Tube Set: Includes a metal luer connector and an overflow reservoir.
• Maintenance: Accompanied by a user manual, with service kits and replacement parts available.

Maintenance and Cleaning

• Servicing: Requires annual or bi-annual servicing at an authorized facility.
• Water Trap Management: The reusable water trap can be steam sterilized, and the pump casing should be cleaned with a 70% alcohol solution.

Safety Guidelines

• Operational Safety: Not suitable for use near flammable gases or water ingress. Intended for short-term operation and should be handled by trained personnel.
• Placement: Should be placed on a secure, level surface away from heat and direct sunlight.

Warranty Information

The device comes with a 12- or 24-month warranty from the shipment date, covering defects in materials and workmanship, provided regular maintenance is conducted at an authorized facility. The warranty may be void if the device is altered or improperly repaired.
