Description

The Volk Pan Retinal® 2.2 Lens is an essential tool for ophthalmologists seeking comprehensive retinal examination and laser treatment capabilities. Designed for use with binocular indirect ophthalmoscopy (BIO), this lens provides exceptional visualization of the mid peripheral and peripheral retina, making it invaluable for diagnosing retinal tears, hemorrhages, and other defects.

Key Features

• Advanced Optics: The lens features patented double aspheric glass optics, offering superior imaging quality. It provides a wider field of view compared to standard 20D lenses, balancing magnification with expansive visibility.
• Ergonomic Design: Its ergonomic design ensures comfortable handling for practitioners of varying hand sizes, enhancing usability during examinations.
• Non-Contact Use: As a classic indirect lens, it is suitable for non-contact applications, even through small pupils.

Technical Specifications

• Field of View: 56° (static) / 73° (dynamic)
• Image Magnification: 2.68x
• Laser Spot Magnification: 0.37x
• Working Distance: 40 mm

Available in both glass and acrylic forms, the lens offers options for sharper imaging or lighter, more resilient handling. Color variants include Black, Blue, Gold, Green, Purple, Red, Silver, Pink, and a special 50th Anniversary Champagne Gold.

Design and Use

The lens's design includes a convex 'belly' side facing the examiner and a flatter side facing the patient. Some versions feature a metallic rim to indicate the patient-facing side. It creates an upside-down, reversed virtual image of the fundus, suitable for both human and veterinary ophthalmology.

Maintenance and Care

Proper care involves regular cleaning with Volk Precision Optical Lens Cleaner or Volk LensPen®. Disinfection should follow manufacturer instructions using recommended high-level disinfectants. For surgical use or contact with ulcerated corneas, comprehensive sterilization methods are compatible, including Ethylene Oxide, Steam, Sterrad, V-Pro, and Sterizone VP4.

Storage and Handling

Store the lens in a clean, dry environment at room temperature. Note that colored rings may discolor with certain disinfectants or repeated sterilization, affecting appearance only. Use Volk Sterilization Case or Tray to prevent damage, and avoid sterilizing Volk black leatherette or clamshell cases.

Additional Features

Each lens comes with a complimentary case, and optional custom engraving is available for both the lens and case, up to 14 characters each. This lens is renowned for its ease of use, making it a popular choice among new ophthalmology residents and general practitioners for general-purpose indirect retinal examination.
